Properties
| Transmission Signal | 1 channel |
| Transmission Distance | 720P: 400M (max) 1080P: 250M (max) |
| Category Type | UTP CAT 5E/6 (R10/100M) |
Video Transmission Properties & Port
| Coaxial Video Connector | BNC-M |
| Twisted-pair Video Connector | Push-terminal |
| Compatible Format | HDCVI |
| Resolution | 720P/1080P |
| Anti-interference | 60db |
Protection
| ESD | 1a contact discharge electricity level 3 1b air discharge electricity level 3 Per:IEC61000-4-2 |
| Coaxial Cable Connector | 2KV(common-code) Per:IEC61000-4-5 |
| UTP Cable Connector | 2KV(different-code),4KV(common-code),Per:IEC61000-4-5 |
Impedance
| BNC Male | 75 ohms |
| UTP Cable | 100 ohms |
Physical Properties
| Dimension(L*W*H) | 53mm*20mm*17mm |
| Shell | ABS |
| Color | Black |
| N.W. | 25G |
| Stability: MTBF | 10000H |
| Operating Temperature | -10~55 |
| Storage Temperature | -20~70 |
| Humidity | 0~95%(non-condensing) |
| Accessories | |
|---|---|
| Technology |
